Brand Name : | Duoli |
Model Number : | 22611 |
Payment Terms : | T/T |
Supply Ability : | 5000pcs/month |
Delivery Time : | Delivery Detail: within 30 days or as per customers' requirement. |
Hydraulic hose fitting BSP Female 60° Cone Swivel Nut by carbon steel
Product Description
Part No. | Thread E | WINNER PART NO. |
01-02-02 | G1/8"×28 | 22611-02-02 |
01-04-04 | G1/4"×19 | 22611-04-04 |
01-06-06 | G3/8"×19 | 22611-06-06 |
01-06-04 | G3/8"×19 | 22611-06-04 |
01-06-08 | G1/2"×14 | 22611-06-08 |
01-08-08 | G1/2"×14 | 22611-08-08 |
01-08-06 | G1/2"×14 | 22611-08-06 |
01-10-10 | G5/8"×14 | 22611-10-10 |
01-12-12 | G3/4"×14 | 22611-12-12 |
01-12-10 | G3/4"×14 | 22611-12-10 |
01-16-16(HEX S38) | G1"×11 | 22611-16-16 |
01-16-12(HEX S38) | G1"×11 | 22611-16-12 |
01-20-20 | G1.1/4"×11 | 22611-20-20 |
01-24-24 | G1.1/2"×11 | 22611-24-24 |
01-32-32 | G2"×11 | 22611-32-32 |
Form:
1. through hole,
2. connector body,
3. Butt joint of threaded pipe,
4. hose butt end,
5. External thread,
6, nuts,
7. groove,
8. cone tooth,
9. The angle between the generatrix of the cone, the A and the cone
and the axis of the butt joint of the threaded pipe.
![]() |
